Depth Capacity: 14,000 ft. w/4 ½" drill pipe

Drawworks


OIME SL-5 with two engine compound, powered by (2) 550HP series 60 Detroit Diesel Engines, WPT 3-24 water cooled aux. brake

Mast

Parco 131’  550,000# static hook load, 6 sheave crown block

Substructure


Parco 18.5’ split level, 467,000# rotary load, 357,000# simultaneous set back

Dog House


10’ by 40’ skidded with electric panel, lockers, and knowledge box
8' by 40' skidded with tool room & wire line unit

Mud Pumps

#1 QZ9 1000HP Triplex, powered by Cat 398
#2 QZ9 1000HP Triplex, powered by Cat 398

Mud system



2 pit (940bbl) system with two 6x8 cent. pumps with 75HP electric motors, 4 Brandt electric mixers, 12 cone de-silter, 2 cone de-sander, Smico 22 sq ft shale shaker

Instrumentation


MD 500,000# wt. ind.– tong, torque – pump pressure gauges, satellite internet system, Pason EDR (electronic drilling recorder) w/interenet access available
Rotary Epuipment

Twister 27 1/2"

Traveling

250 ton Block-Hook, 250 ton Swivel, 5 ¼ hex kelly

Electrical



(2) 350KW generators powered by series 60 Detroit Diesel engines,
Mounted in 10’ wide by 40’ long house, with electric panel and 150KVA Transformer

BOPs/Well Control Equipment



13 5/8" 10,000 # double SL type, 13 5/8 " 5000# Annular, Valvecon 120 gallon, 5 station accumulator – mounted in generator house, 4" 10,000# choke manifold, 4 ft X 19 ft gas separator, buster, and burner

Auxiliary
Equipment


1 Hydraulic winch, (2) 5 ton Air Tuggers, air kelly spinner, air pipe spinner, Varco hydraulic catworks, hydraulic power unit with 50 HP electric motor, (4) air compressors (2) electric, (2) on compound

Drill String

4 1/2" 16.6# X-95 drill pipe (10,000 ft), 4 1/2" 16.6# G-105 (3,000 ft), 18 4 1/2" 42# HW drill pipe, (18) 6 1/4" drill collars, (7) 9" drill collars
Location Size
Optimum 350' X 350', Minimum 260' X 150'




DrawworksOIME SL-5 with (2) 520 HPcat 3406 Eng., WPT 3-24 water brake

MastParco 131’ 550,000# static hook load, 6 sheave crown block

SubstructureParco 18.5’ split level, 467,000# rotary load, 357,000# simultaneous set back

Dog House10’ by 30’ skidded with electric panel, lockers, and knowledge box

Pumps#1 Weatherford MP9 1000 HP Triplex, powered by Cat 398
#2 Weatherford MP9 1000 HP Triplex, powered by Cat 398

Mud System2 pit (900 bbl) system with two 5 x 6 cent. Pumps with 50 HP electric Motors, 4 Brandt electric mixers, 10 cone de-silter, 1 cone de-sander, MCM 27 sq. ft. shale shaker

InstrumentationMD 500,000# wt. ind. – tong, torque – pump pressure gauges, satellite internet system, Pason EDR (electronic drilling recorder) with internet access available

RotaryDreco 27 ½”

Traveling250 ton Block-Hook, 250 ton Swivel, 5 ¼ hex Kelly

Electrical(2) 350 KW generators powered by Series 60 Detroit Diesel engines, Mounted in 10’ wide by 40’ long house, with electric panel and 150 KVA Transformer

BOPs13 5/8” 10,000# double SL type, 13 5/8” 5,000# Annular, Valvecon 120 Gallon, 5 station accumulator – mounted in generator house, 4” 10,000# Choke manifold, 4 ft. x 19 ft. gas separator, buster, and burner

Auxiliary
Equipment		(2) Hydraulic winch, air Kelly spinner, air pipe spinner, Varco Hydraulic Catworks, hydraulic power unit with 50 HP electric motor, (4) air compressors, (2) electric, (2) on compound

Drill String4 ½” 16.6# X-95 drill pipe (10,000 ft), (18) 4 ½” 42#HW drill pipe,(15) 6 ¼” drill collars, (5) 9” drill collars

Location Size350’ x 350’ (opt.)
